ACPRAD AWA
(ACPRAD AWA: Akshar CoPack Perforated RADiant Aluminium Foil + Woven Fabric + Aluminium Foil)
ACPRAD AWA Is a Premium 5-Layer Product Composed of Perforated Radiant Barrier Aluminium Foil, HDPE Woven Fabric and Aluminium Foil. This combination produces a top-class, high-quality product with excellent performance. The perforated design is primarily used as attic foil in residential buildings. The radiant barrier is suitable for attic insulation, especially in under-roof applications and also protects industrial and commercial buildings from temperature variations such as extreme heat and cold. It is ideal for a wide range of thermal insulation applications.
Technical Specification:
| Physical Property | Basic Weight | Tensile Md & Cd | Brust Strength | Temperature Resistant | Reflectivity | Emissivity | Working Temperature |
|---|---|---|---|---|---|---|---|
| Test Value | 150-160 GSM | 300-400 N/25 mm | 315 N/25 mm | Remains Flexible No Delamination | 97% | 0.03% | -50 to 110 °C |
| Test Method | Scale | ASTM D 828 | ASTM D 774 | ASTM C 1263 -29 ~ 66 °C | ASTM E 408 | ASTME408 | Celsius |
**Customized GSM, Thickness, Roll in Size Available as per Client Requirement with Standard Packing.
Remarks: "The technical information provided above represents expected outcomes and is not guaranteed. Product tolerances are: weight & thickness ±10%, width ±5 mm, length ±0.10%. Store the product away from moisture and direct heat at room temperature. Please perform a test application to ensure suitability for your intended purpose before final use."
Features
- 🛡️ Durable 5-layer high-performance heat barrier
- ✨ Reflective film that effectively blocks radiant heat
- 💪 Strong fabric construction resistant to tearing
- 📐 Flexible design suitable for irregular and large surfaces
- 🔧 Withstands wear, stress, and harsh environmental conditions
- 🔥 Lightweight material for easy handling and installation
Application
- 🏠 Attic and under-roof insulation
- 🏭 Factories, warehouses, and commercial buildings
- ❄️ Cold storage facilities and thermal logistics
- 📦 Pallet covers and machinery heat protection
- 🏢 Residential and commercial roofing installations
- 🚚 Transport protection for goods, vehicles, and heavy equipment
Product Benefits
- ☀️ Blocks up to 95% of radiant heat
- 🔄 Reduces summer heat gain and winter heat loss
- 🌡️ Maintains stable indoor temperatures consistently
- 🛡️ Protects goods, equipment, and occupants safely
- ⚖️ Lightweight, durable, and easy to install
- 💰 Saves energy and reduces overall operating costs
